Model JHZ-D Series High-efficient Wet-process Granulator

Features:

Main barrel: The cylinder and cone are tangent to each other, which helps the material to roll. The geometric angles of the stirring paddle and pelletizer are reasonably designed to ensure the best effect of mixed granulation.
The pelletizer is installed at an inclined angle to the straight barrel wall, which can effectively increase the pelletizing range of the pelletizer and the material and improve the uniformity of the particles. At the same time, due to the inclined installation of the pelletizer, the material can be prevented from splashing onto the barrel cover, overcoming the disadvantage that the wet particles will adhere to the barrel cover during traditional pelletizing.
The efficiency of each batch of granulation is 4-5 times higher than that of the traditional process.
The whole process completes dry mixing and wet mixing granulation in the same closed container. Compared with the traditional process, it reduces 25% of adhesives and shortens the drying time.

Operation control system:

controlled by a microcomputer, operated by a touch screen, and can store multiple sets of process data. The pelletizer is variable frequency speed regulation, and its speed can be adjusted arbitrarily to meet the pelletizing requirements of different varieties.
Working principle: The powder is fully stirred by the bottom agitator in the cone-shaped container, and the binder (or paste) is sprayed by pressure to mix the materials into a wet and soft material, and then cut into uniform wet particles by the high-speed granulating knife on the side. When the material is discharged, it is granulated again by the granulator to control the particle size to meet the requirements of various particles.

Its craft：

Application:
JHZ-D series wet granulator (also known as wet mixing granulator) is a special equipment for wet mixing and granulating drug powder, starch, adhesive and paste in the production of food, pharmaceutical and chemical industry preparations. It is also suitable for mixing and granulating powdered materials. This machine is the latest research and development of our company based on the original JHZ-C series wet mixing granulator. It can better meet the process requirements of solid preparation production. It is made of optimized austenitic 304 stainless steel and is equipped with an operating platform, stairs and safety guardrails. It adopts PLC control and frequency conversion speed regulation. All operations can set process parameters according to user requirements, and the original records are true and reliable. It can be used as a single machine or in conjunction with supporting lines. It fully meets the “GMP” requirements for drug production.

Main Technical Parameter：

Product images：
